Maxx Attachments High Dump Rollout Bucket for Skid Steers

Loading a feed truck, a tub grinder or a dump truck full of snow needs more dump height than a skid steer bucket gives, and a rollout bucket adds it. The Maxx Rollout Bucket dumps from a single vertically mounted cylinder, which Maxx says improves the ratio of cylinder stroke to dump motion and cuts the metal fatigue found on two cylinder floor pocket designs. It comes in 0.75, 1.00 and 1.25 cubic yard sizes with a relief valve and replaceable bolt on cutting edges.

Maxx Rollout Buckets are high dump buckets for skid steers and small wheel loaders, popular for loading feed trucks at dairies, feeding tub grinders and working landfills and transfer stations. Maxx lists a single center mounted cylinder with a 2.5 inch bore, 1.25 inch rod and 12 inch stroke, slide links that protect the cylinder from over extension, a standard relief valve, a 1/8 inch moldboard and replaceable bolt on cutting edges.

Maxx High Dump Rollout Bucket Features for Skid Steers

• High dump clearance for loading trucks, tub grinders and high sided containers
• Single vertically mounted center cylinder; Maxx says it is tested and proven to last up to 30,000 hours
• Slide links protect the cylinder from over extension
• Relief valve standard
• Replaceable bolt on cutting edges
• Built for the universal skid steer coupler; Maxx also builds direct mount pin on versions
• Maxx adapted its rollout bucket to skid steers for loading snow into trucks

Maxx Rollout Bucket Sizes

See the Maxx rollout bucket spec sheet (PDF) for the figures Maxx publishes.

Will the Maxx Rollout Bucket Fit My Skid Steer?

The rollout bucket hangs on the universal skid steer coupler, and its dump cylinder runs on the machine's auxiliary hydraulics. Check the bucket weight, 925 to 1,275 pounds empty, plus the load against your machine's rated operating capacity.

Send us your machine make and model before you order and we will confirm the size and fit before your order goes to Maxx.
