SHIELDS 1/2 Inch Front Door Window for Bobcat M-Series Skid Steers

This is the SHIELDS 1/2 inch polycarbonate front door window for Bobcat M-Series skid steers and track loaders, the 28 models from the S450 and S510 through the S650, S770, T650, T770 and T870. It replaces glass 7120401 in the 3 hole pattern or 7155308 in the 2 hole pattern, with the mounting holes duplicated and edges milled so the original door hardware carries over. SUPERCOAT on both sides lets you keep using the wiper. Check your glass number first, since some T550 and T770 machines carry a G-Series window.

The SHIELDS 1/2 inch front windshield door replaces the glass door on Bobcat M-Series skid steers. SHIELDS forms it from polycarbonate to the shape of the original glass, duplicates the mounting holes and mills the edges and holes so your original door hardware carries over, then coats both sides with its SUPERCOAT hard coat. Choose clear or tint, in the 3 hole or 2 hole pattern your door uses.

SHIELDS Bobcat M-Series Front Door Window Features: Bobcat Door Glass Replacement in 1/2 Inch Polycarbonate

• 1/2 inch formed polycarbonate, which SHIELDS rates at more than 260 times the strength of glass at half the weight
• SUPERCOAT hard coat on both sides resists abrasion, so you can keep using your wiper
• Drop-in replacement: mounting holes duplicated and edges milled so the original door hardware carries over
• The 3 hole version comes with a plug in the third hole for machines whose wiper fluid comes from the top; it removes with a flat head screwdriver if you need the hole
• Tint is built into the material, not a film; SHIELDS advises against adding aftermarket tint film because the coating will not hold adhesives
• Made by SHIELDS, which has made windshields since 1975

Bobcat M-Series Door Window Part and Glass Numbers

SHIELDS publishes the material data that applies to this Bobcat M-Series door window: the SHIELDS polycarbonate windshield technical data sheet (PDF) covers impact strength, light transmission and UV resistance, the SHIELDS SUPERCOAT hard coat data sheet (PDF) covers abrasion and chemical resistance, and the SHIELDS polycarbonate vs glass comparison sheet (PDF) compares weight, sound, heat and light by thickness.

Which Bobcat M-Series Skid Steers Does This Door Window Fit?

Fits these Bobcat M-Series models: A770, S450, S460, T460, S510, S530, T530, S550, S560, T550, T560, S570, S590, S595, S630, S650, S740, S750, S770, S850, T450, T595, T630, T650, T740, T750, T770 and T870.

SHIELDS notes that some T550 and T770 machines carry a G-Series window, so check the glass number on your current door: the 3 hole version replaces glass 7120401 and the 2 hole version replaces glass 7155308. The holes are along the bottom edge of the window.

SHIELDS finds the door closes more easily with a 1/2 inch window on this machine when the door striker is moved out slightly.

Send us your machine make, model and serial number, plus the glass number from your current window if you have it, and we will confirm the fit before you order.
