SHIELDS 1/2 Inch Door Window for Case and New Holland Skid Steers

Case SR, SV, TR and TV skid steers and the New Holland L318 and L321 use a curved front door window that SHIELDS makes in four 1/2 inch polycarbonate versions. Two replace glass doors, with the dual wiper arm pattern, glass 47405930, or the single arm pattern, glass 84344565. Two replace the bolt-in OEM polycarbonate doors, 47405929 and 84485211. Plan on longer hinge bolts for the thicker window, and the rubber gasket in the wiper mount comes out. Each version comes clear or tint with SUPERCOAT on both sides.

The SHIELDS 1/2 inch front windshield door replaces the door window on Case SR, SV, TR and TV and New Holland L and C series skid steers. It is formed like the original, coated on both sides with SHIELDS' SUPERCOAT hard coat, and comes in four versions: for glass doors with a dual or single wiper arm, and two bolt-in replacements for the OEM polycarbonate door. Choose clear or tint.

SHIELDS Case SR, SV, TR, TV and New Holland L and C Front Door Window Features: New Holland Skid Steer Door Glass Replacement

• 1/2 inch formed polycarbonate, which SHIELDS rates at more than 260 times the strength of glass at half the weight
• SUPERCOAT hard coat on both sides resists abrasion, so you can keep using your wiper
• Dual wiper arm version replaces glass 47405930 and single wiper arm version replaces glass 84344565
• OEM poly replacement A replaces OEM poly door 47405929 and B replaces 84485211; SHIELDS lists both as dual arm bolt-in doors with 16 bolt holes
• On these doors the 1/2 inch window needs longer hinge bolts, and the rubber gasket in the wiper mount comes out
• Tint is built into the material, not a film; SHIELDS advises against adding aftermarket tint film because the coating will not hold adhesives

Case and New Holland Door Window Part and Glass Numbers

SHIELDS publishes the material data that applies to this Case and New Holland door window: the SHIELDS polycarbonate windshield technical data sheet (PDF) covers impact strength, light transmission and UV resistance, the SHIELDS SUPERCOAT hard coat data sheet (PDF) covers abrasion and chemical resistance, and the SHIELDS polycarbonate vs glass comparison sheet (PDF) compares weight, sound, heat and light by thickness.

Which Case and New Holland Skid Steers Does This Door Window Fit?

The dual wiper arm version fits: L318, L321, SR130, SR130B, SR150, SR150B, SR160, SR160B, SR175, SR175B, SR200, SR200B, SR210, SR210B, SR220, SR220B, SR240, SR240B, SR250, SR250B, SR270, SR270B, SV185, SV185B, SV250, SV250B, SV280, SV280B, SV300, SV300B, SV340, SV340B, TR270, TR270B, TR310, TR310B, TR320, TR320B, TR340, TR340B, TV370, TV370B, TV380, TV380B, TV450 and TV450B.

The single wiper arm version fits: SR130, SR150, SR160, SR175, SR200, SR210, SR220, SR250, SV185, SV250, SV300, TR270, TR320 and TV380.

Check where the wiper mounts on your door: the dual and single arm windows differ in the wiper holes. SHIELDS calls the two OEM poly replacements the 5929 and 5211 bolt-in doors.

Send us your machine make, model and serial number, plus the glass number from your current window if you have it, and we will confirm the fit before you order.
