Connect Work Tools CM Series Hydraulic Magnet for Excavators

Ferrous scrap mixed into demolition, waste and railroad debris is easier to pull out with a magnet whose teeth rake through the pile. Connect Work Tools CMG magnets fit by excavator weight: 38 inch for 28,000 to 34,000 pounds, 42 inch for 38,000 to 46,000 and 50 inch for 52,000 to 64,000. Each needs 10 to 40 GPM, depending on model, from an open center circuit and is rated for a 50 percent duty cycle over 10 minutes. The teeth models carry Esco teeth on a quick fitting device for easy replacement.

The Connect Work Tools CM series is a self contained hydraulic magnet for excavators on demolition, scrap, waste, construction debris and railroad work. It runs off the excavator's auxiliary hydraulic circuit, which drives a generator inside the magnet, so it needs no electrical connection or added generator. Choose a 38, 42 or 50 inch magnet with teeth, or the 42 inch CM42IC on chains. Hydraulic hoses are not included.

Connect Work Tools CM Series Features: Self Contained Hydraulic Excavator Magnet

• Self contained: runs off the auxiliary hydraulic circuit with no electrical connection
• Teeth rake debris to pull out ferrous material
• Standard Esco teeth and keepers on a quick fitting device
• Teeth models mount on a bracket and pins, on a coupler or pinned straight on
• Chain model hangs from a hook on a three leg chain with a central master link
• 50 percent duty cycle over 10 minutes on every model

Connect Work Tools CM Magnet Specifications

Which Connect Work Tools CM Magnet Fits My Excavator?

Pick the model by your excavator's operating weight. Connect calls for an open center hydraulic circuit, with the magnet's tank line going directly to the tank, and 10 to 40 GPM depending on model. The teeth models mount on a bracket and pins, on a coupler or pinned straight on, and the CM42IC hangs from a hook on its chain. Hydraulic hoses are not included. Send us your machine make and model and we will confirm the size and bracket before you order.

Connect Work Tools CMG Magnet Manual and Brochure

Connect Work Tools documents for the CM and CMG magnets, each a PDF:

• Connect Work Tools CMG magnet operator's and parts manual (PDF)
